INSULATING MAT FOR ELECTRICAL PURPOSE: IS 15652: 2006
INSULATING MAT FOR ELECTRICAL PURPOSE: IS 15652: 2006
- ISI mark Insulation Mats are used in substation, power plants, for oor covering below control
panels to provide the safety of workman due to possible leakage of current - Conï€rming to IS 15652: 2006 (Superseding IS: 5424-1969)
- For Both AC and DC application
- Flame Retardant
- High Tensile Strength and Elongation properties
- Finish: One Side Plain other side patterned
- Tensile Strength: 15N/mm2 (min.)
- Elongation at Break: 250% (min.)
- Leakage Current: 10 mA (max.)
- Working Temperature: -10°C to 55°C
-
Materials
-
Industries
-
Size
Class of mat
Thickness
Dielectric Strength
AC RMS Voltage
Roll Size Option 1
Roll Size Option 2
Color
A
2.00mm
30KV
3.3KV
1000mm X 2000mm
1000mm X 10Mtr Long
Black/Blue/Red
B
2.50mm
45KV
11KV
1000mm X 2000mm
1000mm X 10Mtr Long
Black/Blue/Red
C
3.00mm
65KV
33KV
1000mm X 2000mm
1000mm X 10Mtr Long
Black/Blue/Red
